BYD Qin L EV
PRODUCT DETAILS
BYD Qin L EV Electric Sedan Specifications
| Specification | 470KM Leading | 545KM Transcendent | 545KM Excelsior |
|---|---|---|---|
| Basic Information | |||
| Vehicle Class | Mid-size Electric Sedan | Mid-size Electric Sedan | Mid-size Electric Sedan |
| Energy Type | Pure Electric (BEV) | Pure Electric (BEV) | Pure Electric (BEV) |
| Availability | March 2025 | March 2025 | March 2025 |
| Warranty | 6 Years / 150,000 km | 6 Years / 150,000 km | 6 Years / 150,000 km |
| Dimensions & Weight | |||
| Length × Width × Height | 4,720 × 1,880 × 1,495 mm | 4,720 × 1,880 × 1,495 mm | 4,720 × 1,880 × 1,495 mm |
| Wheelbase | 2,820 mm | 2,820 mm | 2,820 mm |
| Front/Rear Track | 1,610 / 1,610 mm | 1,610 / 1,610 mm | 1,610 / 1,610 mm |
| Curb Weight | 1,670 kg | 1,800 kg | 1,800 kg |
| Maximum Load Mass | 2,095 kg | 2,225 kg | 2,225 kg |
| Doors / Seats | 4 Doors / 5 Seats | 4 Doors / 5 Seats | 4 Doors / 5 Seats |
| Trunk Volume | 460 L | 460 L | 460 L |
| Additional Storage | 65 L Front Trunk | 65 L Front Trunk | 65 L Front Trunk |
| Approach/Departure Angle | 13° / 16° | 13° / 16° | 13° / 16° |
| Electric Motor & Performance | |||
| Motor Type | Permanent Magnet Synchronous | Permanent Magnet Synchronous | Permanent Magnet Synchronous |
| Motor Layout | Rear-mounted | Rear-mounted | Rear-mounted |
| Drive Configuration | Single Motor | Single Motor | Single Motor |
| Drivetrain | Rear-Wheel Drive | Rear-Wheel Drive | Rear-Wheel Drive |
| Maximum Power | 110 kW (150 hp) | 160 kW (218 hp) | 160 kW (218 hp) |
| Maximum Torque | 220 N·m | 330 N·m | 330 N·m |
| Top Speed | 160 km/h (99 mph) | 180 km/h (112 mph) | 180 km/h (112 mph) |
| Battery & Range | |||
| Battery Type | Lithium Iron Phosphate (LFP) | Lithium Iron Phosphate (LFP) | Lithium Iron Phosphate (LFP) |
| Battery Brand | FinDreams (BYD) | FinDreams (BYD) | FinDreams (BYD) |
| Battery Capacity | 46.08 kWh | 56.64 kWh | 56.64 kWh |
| CLTC Range | 470 km (292 miles) | 545 km (339 miles) | 545 km (339 miles) |
| Power Consumption | 10.8 kWh/100km | 11.5 kWh/100km | 11.5 kWh/100km |
| Electricity Equivalent Consumption | 1.25 L/100km | 1.34 L/100km | 1.34 L/100km |
| Battery Cooling | Direct Cooling | Direct Cooling | Direct Cooling |
| Battery Preheating | ✓ | ✓ | ✓ |
| Energy Recovery | ✓ | ✓ | ✓ |
| Charging | |||
| Fast Charging (DC) | 24 minutes (30-80%) | 24 minutes (30-80%) | 24 minutes (30-80%) |
| External Discharge (V2L) | ✓ | ✓ | ✓ |
| Suspension & Brakes | |||
| Front Suspension | Dual Ball Joint MacPherson Independent | Dual Ball Joint MacPherson Independent | Dual Ball Joint MacPherson Independent |
| Rear Suspension | Five-Link Independent | Five-Link Independent | Five-Link Independent |
| Steering Assistance | Electric Power Assist | Electric Power Assist | Electric Power Assist |
| Front Brakes | Ventilated Disc | Ventilated Disc | Ventilated Disc |
| Rear Brakes | Solid Disc | Solid Disc | Solid Disc |
| Parking Brake | Electronic | Electronic | Electronic |
| Tire Size | 225/55 R17 | 225/55 R17 | 225/50 R18 |
| Wheel Material | Aluminum Alloy | Aluminum Alloy | Aluminum Alloy |
| Spare Tire | Tire Repair Tools | Tire Repair Tools | Tire Repair Tools |
| Technology & Infotainment | |||
| Center Display | 12.8" Touch LCD | 12.8" Touch LCD | 15.6" Touch LCD |
| Digital Instrument | 8.8" Full LCD | 8.8" Full LCD | 8.8" Full LCD |
| HUD Head-Up Display | - | - | 12" W-HUD |
| Intelligent System | DiLink | DiLink | DiLink |
| Voice Assistant | "Hello, Dee" - 4 Zone | "Hello, Dee" - 4 Zone | "Hello, Dee" - 4 Zone |
| Speech Recognition | ✓ | ✓ | ✓ |
| Navigation System | Amap (AutoNavi) | Amap (AutoNavi) | Amap (AutoNavi) |
| 5G Network & Wi-Fi | ✓ | ✓ | ✓ |
| OTA Updates | ✓ | ✓ | ✓ |
| Car KTV | ✓ | ✓ | ✓ |
| Audio System | 6 Speakers | 8 Speakers | 8 Speakers |
| Built-in Dashcam | ✓ | ✓ | ✓ |
| Wireless Charging | - | - | 50W Front Row |
| USB/Type-C Ports | 2 Front / 2 Rear | 2 Front / 2 Rear | 2 Front / 2 Rear |
| App Store | ✓ | ✓ | ✓ |
| Driver Assistance & Safety | |||
| Assisted Driving Level | L2 | L2 | L2 |
| Driver Assistance System | DiPilot 100 (Triple Vision) | DiPilot 100 (Triple Vision) | DiPilot 100 (Triple Vision) |
| Forward Sensing Cameras | 3 (8MP each) | 3 (8MP each) | 3 (8MP each) |
| Total Cameras | 12 | 12 | 12 |
| Ultrasonic Radars | 12 | 12 | 12 |
| Millimeter-wave Radars | 5 | 5 | 5 |
| Highway Navigation (HNOA) | ✓ | ✓ | ✓ |
| Forward Collision Warning | ✓ | ✓ | ✓ |
| Active Emergency Braking | ✓ | ✓ | ✓ |
| Lane Keeping Assist | ✓ | ✓ | ✓ |
| Automatic Lane Change | ✓ | ✓ | ✓ |
| Traffic Sign Recognition | ✓ | ✓ | ✓ |
| Adaptive Cruise Control | Full Speed | Full Speed | Full Speed |
| Parking Camera | 360° Panoramic | 360° Panoramic | 360° Panoramic |
| Transparent Chassis View | ✓ | ✓ | ✓ |
| Automatic Parking | |||
