BYD Yuan Up
PRODUCT DETAILS
BYD Yuan UP Electric SUV Specifications
| Specification | 301KM Leader | 401KM Leader | 401KM Ultra |
|---|---|---|---|
| Basic Information | |||
| Vehicle Class | Compact Electric SUV | Compact Electric SUV | Compact Electric SUV |
| Platform | BYD e-Platform 3.0 | BYD e-Platform 3.0 | BYD e-Platform 3.0 |
| Energy Type | Pure Electric (BEV) | Pure Electric (BEV) | Pure Electric (BEV) |
| Availability | March 2024 | March 2024 | March 2024 |
| Warranty | 6 Years / 150,000 km | 6 Years / 150,000 km | 6 Years / 150,000 km |
| Dimensions & Weight | |||
| Length × Width × Height | 4,310 × 1,830 × 1,675 mm | 4,310 × 1,830 × 1,675 mm | 4,310 × 1,830 × 1,675 mm |
| Wheelbase | 2,620 mm | 2,620 mm | 2,620 mm |
| Front/Rear Track | 1,570 / 1,570 mm | 1,570 / 1,570 mm | 1,570 / 1,570 mm |
| Curb Weight | 1,430 kg | 1,540 kg | 1,540 kg |
| Doors / Seats | 5 Doors / 5 Seats | 5 Doors / 5 Seats | 5 Doors / 5 Seats |
| Luggage Volume | 1,320 L | 1,320 L | 1,320 L |
| Electric Motor & Performance | |||
| Motor Type | Permanent Magnet Synchronous | Permanent Magnet Synchronous | Permanent Magnet Synchronous |
| Motor Layout | Front-mounted | Front-mounted | Front-mounted |
| Drive Configuration | Single Motor | Single Motor | Single Motor |
| Drivetrain | Front-Wheel Drive | Front-Wheel Drive | Front-Wheel Drive |
| Maximum Power | 70 kW (95 hp) | 130 kW (177 hp) | 130 kW (177 hp) |
| Maximum Torque | 180 N·m | 290 N·m | 290 N·m |
| Top Speed | 150 km/h (93 mph) | 160 km/h (99 mph) | 160 km/h (99 mph) |
| 0-100 km/h Acceleration | 12.0 seconds | 7.9 seconds | 7.9 seconds |
| Battery & Range | |||
| Battery Type | Lithium Iron Phosphate (LFP) | Lithium Iron Phosphate (LFP) | Lithium Iron Phosphate (LFP) |
| Battery Brand | FinDreams (BYD) | FinDreams (BYD) | FinDreams (BYD) |
| Battery Capacity | 32.0 kWh | 45.12 kWh | 45.12 kWh |
| CLTC Range | 301 km (187 miles) | 401 km (249 miles) | 401 km (249 miles) |
| Power Consumption | 12.0 kWh/100km | 12.2 kWh/100km | 12.2 kWh/100km |
| Battery Cooling | Direct Cooling | Direct Cooling | Direct Cooling |
| Battery Preheating | ✓ | ✓ | ✓ |
| Charging | |||
| Fast Charging (DC) | 30-80% in 30 minutes | 30-80% in 30 minutes | 30-80% in 30 minutes |
| External Discharge (V2L) | ✓ | ✓ | ✓ |
| Temperature Management | ✓ | ✓ | ✓ |
| Suspension & Brakes | |||
| Front Suspension | MacPherson Independent | MacPherson Independent | MacPherson Independent |
| Rear Suspension | Torsion Beam Non-Independent | Torsion Beam Non-Independent | Torsion Beam Non-Independent |
| Steering Assistance | Electric Power Assist | Electric Power Assist | Electric Power Assist |
| Front Brakes | Ventilated Disc | Ventilated Disc | Ventilated Disc |
| Rear Brakes | Solid Disc | Solid Disc | Solid Disc |
| Parking Brake | Electronic | Electronic | Electronic |
| Tire Size | 215/65 R16 | 215/65 R16 | 215/65 R16 |
| Wheel Material | Aluminum Alloy | Aluminum Alloy | Aluminum Alloy |
| Spare Tire | Tire Repair Tools | Tire Repair Tools | Tire Repair Tools |
| Technology & Infotainment | |||
| Center Display | 10.1" Touch LCD | 12.8" Touch LCD | 12.8" Touch LCD |
| Digital Instrument | 8.8" LCD | 8.8" LCD | 8.8" LCD |
| Intelligent System | DiLink | DiLink | DiLink |
| Voice Assistant | "Hello, Dee" | "Hello, Dee" | "Hello, Dee" |
| Navigation System | Amap (AutoNavi) | Amap (AutoNavi) | Amap (AutoNavi) |
| 4G Network & Wi-Fi | ✓ | ✓ | ✓ |
| OTA Updates | ✓ | ✓ | ✓ |
| Car KTV | ✓ | ✓ | ✓ |
| Audio System | 6 Speakers | 6 Speakers | 6 Speakers (Optional 8) |
| Built-in Dashcam | - | ✓ | ✓ |
| Wireless Charging | - | - | ✓ Front Row |
| Connectivity Ports | USB + Type-C + SD | USB + Type-C + SD | USB + Type-C + SD |
| Driver Assistance & Safety | |||
| Assisted Driving Level | - | - | L2 (Optional) |
| Cameras | 4 | 4 | 4 (Optional 5) |
| Ultrasonic Radars | 6 | 6 | 6 |
| Millimeter-wave Radars | - | - | 2 (Optional) |
| Forward Collision Warning | - | - | Optional |
| Lane Keeping Assist | - | - | Optional |
| Cruise Control | Standard Cruise | Standard Cruise | Standard + Optional Adaptive |
| Parking Camera | 360° Panoramic | 360° Panoramic | 360° Panoramic |
| Transparent Chassis View | ✓ | ✓ | ✓ |
| Automatic Parking | ✓ | ✓ | ✓ |
| Remote Control Parking | ✓ | ✓ | ✓ |
| Hill Descent Control | ✓ | ✓ | ✓ |
| Hill Start Assist | ✓ | ✓ | ✓ |
| Standard Safety Features | |||
| ABS Anti-lock Braking | ✓ | ✓ | ✓ |
| Electronic Stability Control | ✓ | ✓ | ✓ |
| Traction Control | ✓ | ✓ | ✓ |
| Brake Assist | ✓ | ✓ | ✓ |
| Airbags | Driver + Passenger + Side | Driver + Passenger + Side + Curtain | Driver + Passenger + Side + Curtain |
| ISOFIX Child Seats | ✓ | ✓ | ✓ |
| Tire Pressure Monitoring | Alarm | Alarm | Display |
